4 CH 600W Dante DSP Network Power Amplifier
FHBAVTEC® is top 3 audio system factory in China. FHBAVTEC® 4 CH 600W Dante DSP Network Power Amplifier(D4600), with advanced technology and powerful DSP, which has a 3.97-inch touch LCD screen, supports 4 Dante signal /4 analog signal input, 600W/CH. FHBAVTEC® 4 CH 600W Dante DSP Network Power Amplifier(D4600) can do OEM for customer, make laser logo, production volume for one model will be 2000pcs per day. Leadtime is 15days.
Model:D4600
Send Inquiry PDF DownLoad
Product Description
FHBAVTEC® 4 CH 600W Dante DSP Network Power Amplifier(D4600) Product Introduction:
FHBAVTEC® 4 CH 600W Dante DSP Network Power Amplifier(D4600) is very popular in the market, with powerful DSP chip ,PC DSP software support, passed most Certs like CE,ROHS,FCC etc.
FHBAVTEC® 4 CH 600W Dante DSP Network Power Amplifier(D4600) Product Parameters:
| Series | Dante DSP Network Power Amplifier | ||
| Model | D4600 | D4750 | D4900 |
| 8Ω stereo power | 4x600W | 4x750W | 4x900W |
| Frequency Response | 20 - 20 kHz , ±0.3 dB | ||
| Maximum Input Level | +14 dBu, balanced input | ||
| Maximum Output Level | +14 dBu, balanced output | ||
| THD+N | <0.008% @ 2.2 dBu | ||
| Sampling Rate | 48 KHz | ||
| Number of quantization bits | 24 bit | ||
| Background noise | -88 dBu | ||
| Input Impedance | 20 KΩ (balanced input), 10 KΩ (unbalanced input) | ||
| Output Impedance | 100 Ω (balanced output), 50 Ω (unbalanced output) | ||
| Input Sensitivity | 1.22V | ||
| Input Common State Rejection Ratio | >80dB | ||
| Output Connector | STeakon Block | ||
| USB Interface | Parameter control via TC software operation | ||
| ★Network connection input socket | Connect the amplifier to the network to realize remote parameter adjustment | ||
| ★Network connection output socket | Connect to the next amplifier network input holder for multiple amplifier online operation | ||
| Signal-to-noise Ratio | >112dB | ||
| Damping Coefficient | > 1000@ 8Ω | ||
| Total Harmonic Distortion | <0.1%(20Hz-20 kHz 1W) | ||
| Frequency Response | 20Hz-34KHz(+0/-0.3dB,1W/8Ω) | ||
| Cooling method | Stepless speed control fan, airflow from front to back | ||
| Amplifier protection Method | Short circuit, circuit breaker, DC voltage, overheat, overvoltage, RF, ultra-low frequency protection | ||
| Power Supply Specification | AC voltage 180-240VC (90V-120VAC) 50-60Hz | ||
| Chassis Size (H*W*L) | 88mmX490mmX438mm | ||
| Package Size(H*W*L) | 155mmX600mm×550mm | ||
| Net Weight | 13.5kg | ||
| Gross Weight | 16.5kg | ||
FHBAVTEC® 4 CH 600W Dante DSP Network Power Amplifier(D4600) Main Features:
1. High performance ADI DST processor, high fidelity low noise 24-bit A/D and D/A conversion;
★2.Built-in Dante network transmission module, supporting 4 Dante signal /4 analog signal input,4 groups of digital power amplification output;
★3. Provide USB and RJ45 interface and computer connection;
★4. Each output channel has 8 segments of parameter equalization, frequency division, delay, limiter, gain, polarity;
5. Adopt D class amplifier with high efficiency and high power density, perfect protection function (overcurrent, overheat, high frequency protection);
6. 3.97 inch touch screen, Chinese and English menu operation, display content more comprehensive and intuitive.
FHBAVTEC® 4 CH 600W Dante DSP Network Power Amplifier(D4600) Applications:
DSP power amplifier is suitable for government and enterprise conference, small and medium-sized meeting room, lecture hall, small and medium-sized banquet hall, VIP reception hall, conference center, remote conference and other places.
